Nominal Voltage | 12V |
Rated Capacity | 100Ah (C20) @25°C Ufinal: 10,50 V |
Typical Weight | 31 kg ± 1kg |
Terminal | M8 Female |
Recommended Operation Temperature | 15°C to 30°C |
Maximum Operation Temperature | 50°C |
Storage Temperature | -20°C to 40°C |
Float Voltage | 2,27 V/cell @ 25°C |
Equalizing Voltage | 2,35 V/cell @ 25°C |
Cycle Service Voltage | 2,40 V/cell @ 25°C |
Recommended Maximum Charging Current | 15 A |
Self Discharge | %8-9 after 90 days of storage @ 25°C |
Recommended Terminal Hardware Torque | 9±1 Nm |
Lid and Container Material | ABS UL94 HB (V0 optional) |
Outer Dimensions (L x W x H1 x H2) mm | 331 x 173 x 217 x 220 |
Constant Current Discharge Amperes @25°C | ||||||||||||||||||||||||||||
End Voltage per Cell | 5MIN | 10MIN | 15MIN | 30MIN | 45MIN | 1HR | 2HR | 3HR | 4HR | 5HR | 6HR | 8HR | 10HR | 20HR | ||||||||||||||
1,60V/cell | 359 | 251 | 193 | 117 | 84,5 | 68,1 | 38,8 | 28,1 | 22,1 | 18,5 | 15,8 | 12,2 | 10 | 5,3 | ||||||||||||||
1,65V/cell | 337 | 232 | 186 | 115,1 | 83,8 | 67,7 | 38,6 | 27,6 | 22 | 18,4 | 15,7 | 12,1 | 9,9 | 5,2 | ||||||||||||||
1,70V/cell | 324 | 216 | 183 | 113,1 | 83,2 | 67,2 | 38,3 | 27,4 | 21,8 | 18,1 | 15,5 | 12,1 | 9,9 | 5,2 | ||||||||||||||
1,75V/cell | 305 | 203 | 177 | 112,1 | 82,6 | 66,2 | 37,3 | 27,1 | 21,5 | 18 | 15,4 | 12 | 9,8 | 5,2 | ||||||||||||||
1,80V/cell | 281 | 193 | 165 | 107,2 | 79,2 | 64,5 | 37 | 26,9 | 21,4 | 17,7 | 15,1 | 11,9 | 9,7 | 5,1 | ||||||||||||||
1,85V/cell | 246 | 174 | 147 | 97,8 | 73,5 | 59,7 | 35,1 | 25,4 | 20,2 | 16,6 | 14,2 | 11,2 | 9,2 | 5 |
Constant Power Discharge (Watt per Cell) Amperes @25°C | ||||||||||||||||||||||||||||
End Voltage per Cell | 5MIN | 10MIN | 15MIN | 30MIN | 45MIN | 1HR | 2HR | 3HR | 4HR | 5HR | 6HR | 8HR | 10HR | 20HR | ||||||||||||||
1,60V/cell | 601 | 425 | 339 | 213,5 | 159,2 | 129,5 | 74,3 | 54,3 | 43 | 36,3 | 31,3 | 24,2 | 19,9 | 10,8 | ||||||||||||||
1,65V/cell | 578 | 401 | 331 | 209,9 | 158,2 | 128,5 | 74,1 | 53,6 | 42,9 | 36,1 | 31,1 | 24,1 | 19,7 | 10,7 | ||||||||||||||
1,70V/cell | 567 | 387 | 326 | 209,5 | 158 | 128,1 | 73,8 | 53,6 | 42,7 | 35,8 | 30,9 | 23,9 | 19,5 | 10,7 | ||||||||||||||
1,75V/cell | 536 | 366 | 314 | 209 | 157,2 | 126,5 | 73,4 | 53 | 42,7 | 35,8 | 30,8 | 23,7 | 19,5 | 10,7 | ||||||||||||||
1,80V/cell | 490 | 350 | 295 | 204 | 154,2 | 125,5 | 73,2 | 52,9 | 42,6 | 35,2 | 30,5 | 23,6 | 19,4 | 10,7 | ||||||||||||||
1,85V/cell | 440 | 336 | 270 | 187,1 | 143,3 | 116,5 | 69,9 | 50,2 | 40,5 | 33,6 | 29 | 22,7 | 18,8 | 10,5 |
